Hikvision CA1200 Wireless Router DS-3WRE12C(O-STD)/UK

The Hikvision DS-3WRE12C AC1200 Dual-Band Wi-Fi Extender provides a great wall-plug fix for houses and offices with weak signals. Frequently, basic single-band boosters slow down your speed. Therefore, this smart unit uses two separate wireless bands to keep your internet fast everywhere. Consequently, dead spots vanish completely.

This small device delivers fast speeds up to 1167 Mbps. Specifically, it sends 300 Mbps over the 2.4 GHz band for basic web browsing. Meanwhile, it pushes 867 Mbps over the cleaner 5 GHz band for heavy tasks. Thus, movie streaming and video calls run smoothly without lagging

Key Features

• AC1200 Dual-band Wi-Fi
• Larger WiFi coverage, as well as extreme fast data rate.
• Three steps to configure your repeater

General

• Product Dimension (W × H × D) : 80mm×58mm×48mm
• Package Dimension (W × H × D) : 95mm×98mm×120mm
• Net Weight : 0.221 kg
• Packing List

  WiFi Repeater × 1

  Power Adapter × 1

  Quick Start Guide × 1

  Regulatory Compliance and Safety Information × 1

• Packing Method : Single pack
• Working Temperature : 0 ℃ to 40 ℃ (32 ℉ to 104 ℉)
• Working Humidity : 10% to 90% RH non-condensing
• Storage Temperature : -40 ℃ to 70 ℃ (-40 ℉ to 158 ℉)
• Storage Humidity : 10% to 90% RH non-condensing
• Max. Power Consumption : ≤ 5.2 W
• Gross Weight : 0.243 kg

Wireless Parameter

• Data Rate

  ≤ 1167 Mbps

  2.4 GHz: 300 Mbps

  5 GHz: 867 Mbps

• Wireless Standard : IEEE 802.11/a/n/ac wave 2 @5GHz, IEEE 802.11b/g/n @2.4GHz
• Transmitting Power : 14 ± 1.5 dBm @ 2.4G-mcs7; 14 ± 1.5dBm @ 5G-mcs9
• Wireless Performance : 2*2 MIMO supported
• Receiving Sensitivity

  -63 dB@AC80 -MCS9

  -89 dB@AC80 -MCS0

• Antenna : 2 * External 3dBi dual-band omni-directional antenna

Hardware Parameter

• Network Interface : 1*10/100Mbps RJ45
• LED Indicator

  1 * Signal LED

  1 * WPS LED

  1 * Power LED

• Reset

  1 * WPS Button

  1 * Reset Button

• Power Supply Method : 9VDC, 0.8A, built-in

Software Function

• Application function : Repeater Mode，Access Point Mode
• Security Mode

  Default encryption mode: Mix WPA-PSK/WPA2-PSK

  WPA algorithm: TKIP

• Security Mechanism : Hide SSID
• Management Method : Web
• Upgrade : Web
• System Log : Firmware upgrade, Restore factory settings, Login password, and Reboot
