Key Features
- Deep learning algorithm
- 4.3-inch capacitive touch screen, 2 MP wide-angle dual-lens
- 3,000 face capacity, 3,000 card capacity, 3,000 fingerprint capacity and 150,000 event capacity
- Multiple authentication modes, including face, fingerprint and card, etc.
- Face recognition duration < 0.2 s/User
- Supports mask wearing detection
- Connects to external access controller or Wiegand card reader via Wiegand protocol
- Connects to secure door control unit via RS-485 protocol to avoid the door opening when the terminal is destroyed
- Two-way audio with client software, door station, indoor station, and main station
Display
- Screen size: 4.3 inch
- Operation method: Capacitive touch screen
Video
- Lens: 2
- Resolution: 2 MP (video stream: 720P)
- FOV: HFOV = 41.5°; VFOV = 75.5°; DFOV = 87°
Audio
- Audio quality: Noise suppression and echo cancellation
Network
- Wired network: Support
Interface
- Network interface: 1 RJ-45, 10/100 M self-adaptive
- Lock control: 1
- Exit button: 1
- Door contact input: 1
- TAMPER: 1
- RS-485: 1,RS-485 (Half duplex, HIKVISION）
- Wiegand: 1,Wiegand （Hik 26bit,Hik 34bit）
- USB: 1
Authentication
- Card type: M1 card
General
- Built-in access controller: Support
- Power supply: 12 VDC to 24 VDC, 2 A
- Power consumption: ≤ 10 W
- Working temperature: -30 °C to 60 °C (-22 °F to 140 °F)
- Protective level: IP65
- Language: English, Spanish (South America), Arabic, Thai, Indonesian, Russian, Vietnamese, Portuguese (Brazil), Korean
Function
- Hik-Connect: Support
- QR code recognition: Support
- Face anti-spoofing: Support
