General
|
|
| Shell |
Metal material, fan-free design |
| Net Weight |
0.9 kg (2.0 lb) |
| Gross Weight |
1.4 kg (3.1 lb) |
| Dimensions (W × H × D) |
327.00 mm × 44.00 mm × 118.00 mm (12.87” × 1.73” × 4.65”) |
| Operating Temperature |
0 °C to 40 °C (32 °F to 104 °F) |
| Storage Temperature |
-40 °C to 85 °C (-40 °F to 185 °F) |
| Operating Humidity |
5% to 95% (no condensation) |
| Relative Humidity |
5% to 95% (no condensation) |
| Power Supply |
100-240 V AC, 50/60 Hz, Max. 0.3 A |
| Max. Power Consumption |
12 W |
| Power Consumption in Idle Mode |
2.8 W |
| Installation Mode |
Rack (equipped with mounting ears) |
| Surge Protection |
6 kV |
Network Parameters
|
|
| Ports |
16 × Gigabit RJ45 port |
| MAC Address Table |
8 K |
| Switching Capacity |
32 Gbps |
| Packet Forwarding Rate |
23.81 Mpps |
| Internal Cache |
4.1 Mbits |
Approval
|
|
| EMC |
CE-EMC (EN 55032: 2015 + A11: 2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013 + A1: 2019, EN 50130-4: 2011 + A1: 2014, EN 55035: 2017 + A11: 2020), RCM (AS / NZS CISPR 32: 2015) |
| Safety |
CE-LVD (EN 62368-1: 2014 + A11: 2017), CB (AMD1: 2009, AMD2: 2013, IEC 62368-1: 2014 (Second Edition)) |
| Chemistry |
CE-RoHS (2011/65/EU), WEEE (2012/19/EU), Reach (Regulation (EC) No. 1907/2006) |
