Key Features
- High-quality imaging with 2 MP, 1920 × 1080 resolution
- 24/7 color imaging with F1.0 aperture
- 3D DNR technology delivers clean and sharp images
- 2.8 mm, 3.6 mm, 6 mm fixed focal lens
- Up to 20 m white light distance for bright night imaging
- One port for four switchable signals (TVI/AHD/CVI/CVBS)
Specifications
| Brand | Hikvision |
| Range | ColourVu |
| Image sensor | High-Performance CMOS |
| Maximum resolution | 1080p (1920×1080) to 30 fps |
| Resolution | TVI: 1080p (25~30 fps) CVI: 1080p (25~30 fps) AHD: 1080p (25~30 fps) CVBS: PAL/NTSC |
| Lens | 3.6 mm |
| Viewing Angle (FOV) | 76º (H), 41º (V), 115º (D) |
| Minimum illumination | 0.001 Lux @ (F1.0, AGC ON), 0 lux with white light range 20 m |
| Day / Night | Color |
| Video output | 1 x BNC switchable between HDTVI / HDCVI / AHD / CVBS |
| Video output switching | Via Switch |
| Basic functions | OSD menu (remote) |
| Configurable OSD functions | DWDR, BLC, HLC, 3DNR/2DNR, AGC, AWB, Mirror function, Smart Light |
| Communication | HIKVISION-C |
| Lens Adjustment | 3 Axis |
| Power | DC 12 V / 2.4 W max. |
| Degree of protection | Suitable for interior |
| Temp. operation | -40º C ~ +60º C |
| Material | Plastic |
| Dimensions | Ø 85.02 mm x 81.25 mm (H) |
| Base diameter | Ø base 85.02 mm / Ø entre tornillos 60 mm / 3 tornillos |
| Weight | 161 g |
