Key Features
- 8 x 10/100 Mbps ethernet ports
- Supports ADI/ADIX
- Store-and-forward switching
- Supports MAC address auto-learning and aging
- Simple, compact body design
- Supports desktop and wall-mounting
- Plug & play, easy to use.
Specification
| Port number | 8 |
| Port type | 10/100 Mbps RJ45 ports |
| Standard | IEEE 802.3, IEEE 802.3u, IEEE 802.3x |
| Forwarding mode | Store and forward |
| MAC address table | 1 K |
| Switching capacity | 1.6 Gbps |
| Packet forwarding rate | 1.1904 Mpps |
| Shell | ABS |
| Temperature | Operating: 0°C~40°C
Storage: -40°C~70°C |
| Humidity | Operating: 10%~90% RH non-condensing
Storage: 5%~90% RH non-condensing |
| Power supply | 5 V DC, 0.6 A |
| Dimensions (L × H × D) | 124 × 59 × 23.2 mm |
| Weight | 0.041 kg |
Product Applications
- Small business office network expansion
- Home office network enhancement
- Temporary networking setup for events or trade shows
