Key Features
- 8 channels and 1 HDD 1U AcuSense DVR
- Support 4-ch Facial Recognition or 8-ch advanced model Perimeter Protection based on Deep Learning algorithm
- Support 8-ch AcuSearch Technology
- Encoding ability up to 4K/8MP @ 8fps; 3K/5MP @12fps
- Up to 16 channels IP camera inputs, each channel up to 8MP
- Up to 24*1080P@30fps decoding ability
- 5 signals input adaptively (HDTVI/AHD/CVI/CVBS/IP)
- Support All channels Motion Detection Technology
- Support All channels HDTVI Two-Way Audio Technology
Specification
Facial Recognition
- Face Picture Library
Up to 16 face picture libraries;
HDD damage will not cause data loss in the face picture library, because the library has been backed up by HDD and flash.
- Face Picture Comparison: 4-ch face picture comparison alarm (HD analog camera)
Perimeter Protection
- Human/Vehicle Analysis: Up to 8-ch (advanced model)
Facial Detection
- Facial Detection and Capture
Face picture detection, face picture search；
4-ch face picture capture
Video and Audio
- IP Video Input
8-ch (up to 16-ch), each up to 4 Mbps
Support H.265+/H.265/H.264+/H.264 IP cameras
- Analog Video Input
8-ch
BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
- HDMI Output
1-ch, 4K (3840 × 2160)/30Hz,
2K (2560 × 1440)/60Hz,
1920 × 1080/60Hz,
1280 × 1024/60Hz,
1280 × 720/60Hz
HDMI/VGA simultaneous output
- VGA Output
1-ch, 1920 × 1080/60Hz,
1280 × 1024/60Hz,
1280 × 720/60Hz
HDMI/VGA simultaneous output
- CVBS Input PAL/NTSC
- CVBS Output
1-ch, BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704 × 576, NTSC: 704 × 480
- Synchronous Playback: 8-ch
- HDTVI Input: 8 MP (3840 × 2160) @12/15 fps, 3K (2960 x 1665) @25/20 fps,3K (3328×1504) @20fps,5 MP (2560 × 1944) @20 fps, 4 MP (2560 × 1440) @25/30 fps,1080P@25/30 fps, 720P@25/30fps
- AHD Input: 5 MP (2560 × 1944) @20 fps, 4 MP (2560 × 1440) @25/30 fps,1080P@25/30 fps, 720P@25/30fps
- HDCVI Input: 8 MP (3840 × 2160) @12/15 fps, 3K (2880×1620) @25fps, 5 MP (2592 × 1944) @20 fps, 4 MP (2560 × 1440) @25/30 fps,1080P@25/30 fps, 720P@25/30fps
- Audio Output: 1-ch, RCA (Linear, 1 KΩ)
- Audio Input: 1-ch, RCA (2.0 Vp-p, 1 KΩ)，8-ch via coaxial cable
- Two-Way Audio: 1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)
Recording
- Video Compression: H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
- Encoding Resolution: 8 MP/5 MP/3K/4 MP/3 MP/1080p/720p/WD1/4CIF/VGA/CIF
- Frame Rate
Mainstream:
8 MP@8 fps/3K@12 fps/5 MP@12 fps/4 MP@15 fps/8 MP Lite@15 fps/1080p/720p@25 fps (P)/30 fps (N)
Sub-stream:
WD1/4CIF/CIF@25 fps (P)/30 fps (N)
- Video Bitrate: 32 Kbps to 10 Mbps
- Dual stream: Support mainstream or sub stream
- Stream Type: Video, Video & Audio
- Audio Compression: G.711u
- Audio Bitrate: 64 Kbps
Decoding
- Decoding Capability: up to 24-ch 1080P@30fps
Network
- Total Bandwidth: 256 Mbps
- Network Protocol: TCP/IP, PP PoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF, ISUP
- Remote Connection: 64
- Network Interface: 1, RJ45 10M/100M/1000M self-adaptive Ethernet interface
Auxiliary Interface
- SATA: 1 SATA interface
- Capacity: up to 12 TB capacity for each disk
- Serial Interface: RS-485 (half-duplex)
- USB Interface
Front panel: 1 × USB 2.0;
Rear panel: 1 × USB 3.0
- Alarm In/Out: N/A (optional to support)
General
- Power Supply: 12 VDC, 2 A
- Consumption: ≤ 10 W (without HDD)
- Working Temperature: -10 °C to 55 °C (14 °F to 131 °F)
- Working Humidity: 10% to 90%
- Dimension (W × D × H): 319 × 240 × 48 mm (12.6 × 9.4 × 1.9 inch)
- Weight: ≤ 2 kg (4.4 lb)
