Key Features
- High-quality imaging with 4 MP resolution
- Dual transducers – PIR and Radar work together for higher detection accuracy
- Support 4G LTE data transmission
- Built-in microphone and built-in speaker for two-way audio and audio alarm
- Support on-board storage up to 512 GB (SD card slot)
- Water and dust resistant (IP66)
- Support manual adjustment of the radar angle: 0°, 10°, and 20°
Camera
- Image Sensor: 1/2.7″ Progressive Scan CMOS
- Max. Resolution: 2560 × 1440
- Min. Illumination: Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR
- Shutter Time: 1/3 s to 1/100,000 s
- Day & Night: IR cut filter
Lens
- Lens Type: Fixed focal lens, 2.8 and 4 mm optional
- Focal Length & FOV
2.8 mm, horizontal FOV 94°, vertical FOV 49°, diagonal FOV 114°
4 mm, horizontal FOV 70°, vertical FOV 35°, diagonal FOV 85°
- Lens Mount: M12
- Iris Type: Fixed
- Aperture: F1.6
PTZ
- Movement Range (Pan): 0° to 340°
- Movement Range (Tilt): 0° to 80°
- Pan Speed: Up to 25°/s
- Tilt Speed: Up to 25°/s
- DORI
- DORI
2.8 mm, D: 68 m, O: 27 m, R: 13 m, I: 6 m
4 mm, D: 100 m, O: 39 m, R: 20 m, I: 10 m
Illuminator
- Supplement Light Type: IR
- Supplement Light Range: Up to 30 m
- Smart Supplement Light: Yes
- IR Wavelength: 850 nm
Video
- Mainstream
50 Hz: 12.5 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
60 Hz: 15 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
- Sub-Stream
50 Hz: 12.5 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 15 fps (1280 × 720, 640 × 480, 640 × 360)
- Video Compression
Mainstream: H.265/H.264,
Sub-stream: H.265/H.264/MJPEG
- Video Bit Rate: 32 Kbps to 8 Mbps
- H.264 Type: Baseline Profile, Main Profile, High Profile
- H.265 Type: Main Profile
- Bit Rate Control: CBR, VBR
- Region of Interest (ROI): 1 fixed region for mainstream
Audio
- Audio Type: Mono sound
- Audio Sampling Rate: 8 kHz/16 kHz
- Environment Noise Filtering: Yes
- Audio Compression: G.722.1/G.711/MP2L2/PCM/G.726/AAC-LC
- Audio Bit Rate: 16 Kbps (G.722.1)/64 Kbps (G.711ulaw/G.711alaw)/32~160 Kbps (MP2L2)/8~48 Kbps (PCM)/16 Kbps (G.726)/16~64 Kbps (AAC-LC)
Network
- API: ONVIF (Profile S, Profile G, Profile T), ISAPI, SDK
- Security: Password protection, complicated password, basic and digest authentication for HTTP, TLS 1.1/1.2/1.3, WSSE and digest authentication for Open Network Video Interface
- Simultaneous Live View: Up to 6 channels
- Protocols: TCP/IP, DHCP, IPv4
- User/Host
Up to 32 users
- Wide Dynamic Range (WDR): Digital WDR
- SNR: ≥ 52 dB
- Day/Night Switch: Day, Night, Auto, Schedule
- Image Enhancement: BLC, HLC,3D DNR
- Image Settings: Saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser
Transducer
- Transducer Type: PIR + Radar
- Detection Angle: Horizontal: 80°, vertical: 30°
- Detection Range: Up to 12 m
Interface
- Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port
- On-Board Storage: Built-in memory card slot, support microSD/micro SDHC/micro SDXC card, up to 512 GB
- Built-in Microphone: 1 built-in microphone
- Built-in Speaker: 1 built-in speaker, Max. power consumption: 1.5 W, max. sound pressure level: 10 cm: 95 db.
- Reset Key: Yes
Event
- Basic Event: Motion detection (support alarm triggering by specified target types (human and vehicle)), video tampering alarm, exception
- Linkage Upload to FTP/memory card, notify surveillance center, trigger recording, trigger capture, audible warning
General
- Power
Power Consumption and Current:
Typical power scenarios: 1.85 W (4G working)
Standby scenarios: 80 mW
Max. Power consumption: 7 W
Power Supply: 12 VDC ± 25%
*For debugging only
10 W (deviation: ± 5%) Solar panels
Power Interface:
Power supply interface: four-core aviation connector
Externed solar panel: four-core aviation connector
- Dimension: 133.1 mm × 177.64 mm × 382.44 mm/412.44 mm (5.24″ × 6.99″ × 15.06″/16.24″)
- Material: Plastic
- Package Dimension: 375 mm × 305 mm × 398 mm (14.76″ × 12.01″ × 15.67″)
- Weight: Approx. 850 g (1.87 lb.)
- With Package Weight: Approx. 5400 g (11.88 lb.)
- Storage Conditions: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- Startup and Operating Conditions: 0 °C to 50 °C (32 °F to 122 °F). Humidity 95% or less (non-condensing)
- Language English, Ukrainian
- General Function: Heartbeat, anti-banding, mirror, password protection, password reset via email
Battery
- Battery Type: Ternary Lithium
- Cycle Lifetime
27 hours (1.85 W)
Full charge battery runtime without solar input.
- Battery Voltage: 9 V to 12.6 V
- Capacity: 50.76 Wh
- Max. Charging Voltage: 12.6 V
- Max. Output Voltage: 12.6 V
- Operating Temperature
Charging: 0 °C to 45 °C (32 °F to 113 °F)
Discharging: -20 °C to 55 °C (-4 °F to 131 °F)
- Battery Life: More than 800 cycles
Approval
- RF
CE-RED: EN 301489-1 V2.1.1 (BT or 2.4G), EN 301489-17 V3.1.1 (BT or 2.4G), EN 300328 V2.1.1 (BT or 2.4G), EN 62311: 2008 (BT or 2.4G)
*CE certification is only for the device sold in the European region.
- EMC
CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021,
IC: ICES-003: Issue 7,
KC: KN32: 2015, KN35: 2015
- Safety
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017,
BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005
- Environment
CE-RoHS: 2011/65/EU,
WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006
Protection
- IP66: IEC 60529-2013
