Key Features
- VA technology, 178° ultra-wide view screen.
- 8-bit LVDS FHD (1920 × 1080) display.
- 100 Hz refresh rate, more fluid and life-like video
- Ultra-thin device body with ultra-thin border for 3 sides.
- 3D noise reduction.
- Low blue light design for eye care.
- Dual interface of HDMI and VGA.
- Support VESA wall mount.
Display |
|
| Screen Size | 21.45 inch |
| Active Display Area | 478.656 (H) mm × 260.280 (V) mm |
| Resolution | 1920 × 1080 |
| Backlight | E-LED |
| Pixel Pitch | 0.241 (H) mm × 0.241 (V) mm |
| Brightness | 250 cd/m² |
| Viewing Angle | 178° (H)/178° (V) |
| Color Depth | 8-bit, 16.7 M |
| Contrast Ratio | 1000:1 |
| Response Time | 6.5 ms |
| Refresh Rate | Max. 100 Hz, Typ. 60 Hz |
| Haze | Haze 25%, 3H |
| Reliability | 7 × 16 H |
| Color Gamut | 72% NTSC |
| Interface | |
| Video & Audio Input | HDMI 1.4 × 1, VGA × 1 |
| Video & Audio Output | Audio Out |
| Power | |
| Power Supply | DC 12V, 2.0A |
| Power Consumption | ≤ 24 W |
| Standby Consumption | ≤ 0.5 W |
| Working Environment | |
| Working Temperature | 0 °C to 40 °C (32 °F to 104 °F) |
| Working Humidity | 20% RH to 90% RH (Non-Condensing) |
| Storage Temperature | -20 °C to 60 °C (-4 °F to 140 °F) |
| Storage Humidity | 10% RH to 90% RH (Non-Condensing) |
| General | |
| Casing Material | Plastic |
| VESA | 75 mm × 75 mm (4 – M4 × 6 mm) |
| Bezel Width | 2.38 mm (top/left/right), 21.55 mm (bottom) |
| Product Dimensions (W × H × D) | With base: 493.26 (W) mm × 393.45 (H) mm × 185.74 (D) mm (19.42” × 15.49” × 7.31”) Without base: 493.26 (W) mm × 290.13 (H) mm × 42.35 (D) mm (19.42” × 11.42” × 1.67”) |
| Package Dimensions (W × H × D) | 599 (W) mm × 393 (H) mm × 109 (D) mm (23.58” × 15.47” × 4.29”) |
| Net Weight | 2.0 ± 0.5 kg (4.41 ± 1.10 lb.) |
| Gross Weight | 3.2 ± 0.5 kg (7.05 ± 1.10 lb.) |
| Packing List | Monitor × 1, Base component × 1, Power adapter (12 V, 2.0 A) × 1, HDMI cable (1.5 m) × 1, User manual × 1, Multilingual manual × 1 |
| Remarks | The base is included by default. The product appearance and parameters in this specification may vary from your actual device. Please consult our local sales staff for further information |
